What Is a Coin Operated Carousel?
A coin operated carousel ride, also known as a kiddie merry go round, is a small amusement attraction for children. Riders insert coins or tokens to start the ride, which rotates safely with cheerful music and colorful LED lights.
Key Characteristics of Coin Operated Carousel Horse
- Compact size, ideal for shopping malls and playgrounds
- Available in 3-seat, 6-seat, or larger models
- Combines rotation with gentle up-and-down horse movement
- Simple payment system: coins, tokens, or a smart card
Main Features of Coin Operated Carousel Rides
🎠 Classic Design – FRP horses or carriages with luxury painting
💡 LED Lighting – Bright, colorful, and energy-efficient
🎵 Music System – Preloaded cheerful tunes with adjustable volume
🪙 Flexible Payment – Coin, token, card swipe, or online payment options
⚙️ Customizable Options – Seats, colors, and themes available
🔒 Safety Systems – Leakage protection, secure seats, and low-speed operation
Technical Specifications of Coin Operated Carousels
| Item | 3-Seat Carousel Specs | 6-Seat Carousel Specs |
| Voltage | AC 220 V 50 Hz | AC 380 V |
| Power | 750 W | 1100 W |
| Capacity | 3 children | 6 children |
| Seat Load | 40 kg × 2 | 50 kg per seat |
| Total Height | 2.38 m | 2.83 m |
| Diameter | Ø 1.15 m | Ø 2.3 m |
| Ride Time | 1–5 minutes (adjustable) | 1–5 minutes (adjustable) |
| Rotation Speed | – | 6 rpm |
| Safety Device | Leakage protection | Leakage protection |
| Note | Specs subject to updates | Specs subject to updates |
Installation Guide for Coin Operated Carousel Kiddie Rides
Step-by-Step Setup
- Site Selection – Flat ground, ≥2.8 m clearance
- Base Installation – Secure the main frame and adjust foot screws
- Wiring Setup – Connect cables correctly; ensure proper grounding
- Horse Assembly – Install fiberglass horses or seats securely
- Control Box Configuration – Connect coin acceptor, set coins & ride time
- Testing – Run carousel without passengers to check stability
Mini Carousel Operation Instructions
How to Operate Safely
- Standby Mode – Switch on power; system self-checks
- Payment – Insert coins/tokens; ride activates
- Ride Experience – Horses rise and fall while carousel rotates with music
- Stop – Ride ends automatically after preset time
- Emergency Stop – Use the emergency button if needed
Mini Merry go Round Maintenance and Care Tips
- Daily Checks – Bolts, wiring, horse fixtures
- Lubrication – Apply grease weekly to moving parts
- Cleaning – Wash fiberglass with mild detergent, polish with wax
- Electrical Check – Test leakage protector and emergency stop button
- Seasonal Maintenance – Oil replacement, welding check, parts replacement
Troubleshooting Common Issues
| Problem | Cause | Solution |
| Carousel won’t start | No power / blown fuse | Check power, replace fuse |
| Coin not accepted | Dirty/faulty coin slot | Clean or replace acceptor |
| No music/lights | Speaker/wiring issue | Reconnect or replace |
| Horses not moving | Loose chain / worn shaft | Tighten or replace parts |
| Breaker trips | Short circuit / leakage | Inspect wiring, fix faults |
Safety Guidelines for Coin Operated Kiddie Carousel Rides
- One child per horse, ≤50 kg weight limit
- Children under 10 require adult supervision
- Never board or exit while moving
- Stop operation in case of thunderstorm or strong wind
- Always have staff supervising
Conclusion
A coin operated carousel ride is an ideal amusement attraction for both indoor and outdoor venues. With easy installation, reliable operation, and simple payment systems, it offers long-term profitability for operators while delighting children.
👉 Looking for a trusted supplier? Explore our Mini Carousel Rides for Sale with factory-direct pricing, customization options, and professional after-sales support.
